embedded system/ embedded PC/ Box PC/ Mini ITX Case
| Payment Terms: |
T/T |
| Place of Origin: |
Guangdong, China (Mainland) |
Product Detail
Model No.:
IEC-622DB
Production Capacity:
2000pcs/month
Delivery Date:
5-10days
Means of Transport:
Air
Packing:
cartons
Embedded PC IEC-622DB
Intel Atom Dual-core D525 CPU, 2GB DDR3, Dual Intel GbE Lan card, VGA, USB2.0, Audio, 4 COM, LPT, Power adapter
| Wide temperature fanless embedded system |
- Low power Intel Atom Dual-core D525 processor, 1.8GHz, 1MB L2 cache
- Two 204-pin DDR3 SO-DIMM slot, up to 4GB; Preloaded 2GB DDR3 memory
- Two Intel GbE controller
- Supports Line out, MIC interface, built-in 2x6W sound amplifier; Optional 2x2W speaker
- One built-in Mini PCIe slot, one PCI slot, for expanding
- DC 12V input,3 pin connector; Optional 9~28V wide voltage input
|
| Color | Black |
| Dimensions(DxWxH) | 200x300x75mm |
| Material | Aluminum extrusion cover, sheet metal chassis |
| Platform | Intel Pineview-D Platform |
| CPU | Intel Atom 45nm dual core D525 1.8GHz processor, 1MB L2 cache |
| Chipset | Intel ICH8M |
| BIOS | SPI FLASH BIOS |
| System memory | Two 204pin DDR3 SO-DIMM slots, up to 4GB; Preloaded 2GB DDR3 memory |
Interface
| Three SATA interfaces, one IDE interface, one CF slot |
| HDD | Supports one 2.5"HDD bay, One SATA power connector |
| CF slot | One CF slot, supports master/slave setting |
| Ethernet | Dual Intel PCIe GbE controller
Two 10/100/1000Mbps RJ-45 LAN ports |
| USB | Four USB2.0 |
| Display | One DB-15 VGA port, supports hot plug, resolution up to 2048x1536 |
| RS232 COM | Two RS-232 |
| RS232/422/485 COM | Optional two RS-232/422/485; Default RS-232 |
| Audio | One Line out, one MIC interface, built-in 2x6W amplifier |
| Keyboard/Mouse | One PS/2 Keyboard/mouse interace |
| Indicator | One power LED, One HDD LED |
| WDT | Software programmable supports 1~255 sec system reset |
| Expansion | One Mini PCIe slot, for WiFi module |
DC in & power connector
| Single voltage 12V input, 3 Pin power connector |
Power consumption
| 12V/1.8A (Intel® D525 1.8GHz/DDR3 2GB) |
| Power adapter | 120W DC power adapter, 100 ~ 240V AC input, DC 12V output |
| Mounting | Supports wall-mounting or desktop-mounting |
Operate temperature
| -20°C ~ 50°C (With SATA HDD or WiFi module);
-20°C ~ 70°C (With SATA SSD/ CF card) |
Storage temperature
| -20°C ~ 75°C |
IP level
| Front panel IP64 |
| Operate humidity | 5% ~ 85% non-condensing @ 40℃ |
| Storage humidity | 5% ~ 95% non-condensing |
| Shock | Half sine wave 3G; 11ms 3axis |
| Vibration | MIL-STD-810F 514.5C-1 (With SATA HDD); MIL-STD-810F 514.5C-2 (With SATA SSD/CF) |
| Weight | 4 Kg |
| Model No. | Descriptions |
| IEC-622DB | Wide temperature fanless embedded system, Intel Atom Dual-core D525 CPU, 2GB DDR3 Ram,160GB SATA HDD, Dual Intel GbE Lan card, VGA, USB2.0, Audio, 4 COM, LPT, Power adapter |
| IEC-622DBL | Wide temperature fanless embedded system, Intel Atom Dual-core D525 CPU, 2GB DDR3 Ram,160GB SATA HDD, Dual Intel GbE Lan card, VGA, USB2.0, Audio, 4 COM, LPT, 9~28V input |
| IEC-622DBW | Wide temperature fanless embedded system, Intel Atom Dual-core D525 CPU, 2GB DDR3 Ram,160GB SATA HDD, Dual Intel GbE Lan card, VGA, USB2.0, Audio, 4 COM, LPT, WiFi Module, Power adapter |
